Codes
l
44
EDS82ZAFVCxxx EN 4.0
C1511:
Configuration of process output data
Code
Subcode
Possible settings
Data type
Lenze
Selection
C1511
FIX32
1 (PAW1)
1
See table below
2 (PAW2)
3
3 (PAW3)
4
4 (PAW 4)
5
5 (PAW 5)
6
6 (PAW 6)
7
7 (PAW 7)
8
8 (PAW 8)
9
9 (PAW 9)
10
10 (PAW 10)
11
11 (PAW11)
13
12 (PAW12)
14
The assignment of the process data output words (PAW) of the master to bit control
commands or setpoints of the controller can be freely configured with C1511.
Selection
Scaling
1
FIF control word 1 (FIF−CTRL1)
16 bits
2
FIF control word 2 (FIF−CTRL2)
16 bits
3
Setpoint 1 (NSET1−N1)
±24000
º ±480 Hz
4
Setpoint 2 (NSET1−N2)
±24000
º ±480 Hz
5
Additional setpoint (PCTRL1−NADD)
±24000
º ±480 Hz
6
Actual process controller value (PCTRL1−ACT)
±24000
º ±480 Hz
7
Process controller setpoint (PCTRL1−SET1)
±24000
º ±480 Hz
8
reserved
9
Torque setpoint / limit value (MCTRL1−MSET)
2
14
º 100 % rated motor torque
10
PWM voltage(MCTRL1−VOLT−ADD)
(
Only for special applications. Please
contact Lenze!
11
PWM angle (MCTRL1−PHI−ADD)
12
reserved
13
FIF−IN.W1
16 bits or 0 ... 65535
14
FIF−IN.W2
16 bits or 0 ... 65535
15
FIF−IN.W3
0 ... 65535
16
FIF−IN.W4
0 ... 65535
