Codes 8
l
39 EDS82ZAFVCxxx EN 4.0
Transmitting the parameter sets with the keypad:
Selection Important
Using the keypad, you can transmit the parameter sets to the other controllers.
During the transmission the access to the parameters via other channels is inhibited!
Keypad ð controller Overwrite all available parameter sets (PAR1 ... PAR4, or if
required FPAR1) with the corresponding keypad data
70 with DeviceNet function module
10 (other)
Keypad
ð PAR1 (+ FPAR1) Overwrite the selected parameter set and, if necessary, FPAR1
with the corresponding keypad data
71 with DeviceNet function module
11 (other)
Keypad
ð PAR2 (+ FPAR1)
72 with DeviceNet function module
12 (other)
Keypad
ð PAR3 (+ FPAR1)
73 with DeviceNet function module
13 (other)
Keypad
ð PAR4 (+ FPAR1)
74 with DeviceNet function module
14 (other)
Controller
ð keypad Copy all available parameter sets (PAR1 ... PAR4, or if required
FPAR1) into the keypad
80 with DeviceNet function module
20 (other)
Keypad
ð function module Only overwrite the module−specific parameter set FPAR1 with
the keypad data
40 only with DeviceNet function module
Function module
ð keypad Only copy the module−specific parameter set FPAR1 into the
keypad
50 only with DeviceNet function module
Save own basic settings:
Selection Important
9 PAR1 ð own basic setting You can store an own basic setting for the controller
parameters (e. g. the delivery state of your machine):
1. Ensure that parameter set 1 is active
2. Inhibit the controller
3. Set C0003 = 3, confirm with
v
4. Set C0002 = 9, confirm with v, the own basic setting is
stored
5. Set C0003 = 1, confirm with v
6. Enable the controller
With this function you can simply copy PAR1 into the
parameter sets PAR2 ... PAR4
5 Own basic setting ðPAR1 Restoring the own basic setting in the selected parameter set
6 Own basic setting ðPAR2
7 Own basic setting ðPAR3
8 Own basic setting ðPAR4
