Lenze DISCO−Variable speed drive User Manual
Page 8
l
8
BA 11.5032−EN 3.0
DISCO variable speed drive with helical−bevel gearbox and helical−worm gearbox
GKS
LL − LD / GSSLL − LD
Solid shaft: 2, 3, 8 (3+5)
Hollow shaft: 0
Hollow shaft with shrink disc: 3, 5
Flange: 2, 3, 8 (3+5)
Without flange: 0
Terminal box: 2, 3, 4, 5
Spindle housing: 2, 3, 4, 5
Handwheel/adjusting device: 2, 3, 4, 5
A
B
C
D
E
F
