Product key
DISCO variable speed drive with rear−mounted gearbox LLL LL − L D L L L LLL − LL LLL
0
1
2
3
4
5
6
7
Lengend for the product key
0
Gearbox type GST
GKS
GSS Helical gearbox
Helical−bevel gearbox
Helical−worm gearbox
1 Gearbox size
2 Number of stages
3 Disco variable speed drive
4 Output design V
H
S Solid shaft
Hollow shaft
Hollow shaft with shrink disk
5 A
B
C Foot mounting, with centring
Foot mountin, without centring
Without foot, with centring
6 R
K
l Without flange
With flange (through holes)
With flange (threaded holes)
7 Drive size Motor frame size
motor design
DISCO size
