Lenze DISCO−Variable speed drive - Manual (Page 31)

Appendix 10
l
31 BA 11.5032−EN 3.0
Pos. Name
0.25 Seal
0.26 Seal
0.28 Hexagon head cap screw
0.29 Locking washer for sizes 02−03
Spring washer for sizes 04−07
0.30 Cheese head screw
0.31 Spring washer
0.40 Oil sight glass
0.41 Locking screw
0.42 Angled breather tube
2.01 Cover
2.02 Shaft
2.04 Housing
2.05 Flange
2.06 Fan cover
2.07 Socket
2.08 Three−phase AC motor
2.09 Fan
2.10 Starting coupling
2.11 Flexible coupling
2.15 Deep−groove ball bearing
2.16 Deep−groove ball bearing
2.17 Inner ring
2.18 Shaft sealing ring
2.19 Circlip
2.20 Circlip
2.21 Circlip
2.22 Featherkey
2.23 Featherkey
2.24 Featherkey
2.25 Shim ring
2.27 Seal
2.28 Set screw
2.29 Set screw
2.30 Hexagon head cap screw
2.31 Locking washer for sizes 02−03
Spring washer for sizes 04−07
2.32 Cheese head screw
2.33 Seal
2.34 Cheese head screw
2.35 Spring washer
2.36 Hexagon head cap screw
2.37 Hexagon nut
2.38 Spring washer
3.01 Cover
3.03 Flange
3.05 Shaft
3.08 Hub
3.09 Pinion cage
3.10 Slide block
3.11 Socket
3.12 Washer
3.14 Clutch collar
3.15 Ball retainer ring
3.16 Clutch thrust collar
3.17 Flange
Pos. Name
3.19 Socket
3.26 Socket
3.27 Pressure spring
3.28 Deep−groove ball bearing
3.29 Deep−groove ball bearing
3.32 Deep−groove ball bearing
3.36 Shaft sealing ring
3.38 Circlip
3.39 Circlip
3.40 Circlip
3.41 Circlip
3.51 Circlip
3.52 Dowel pin
3.53 Hexagon head cap screw
3.56 Dowel pin
3.57 Dowel pin
3.58 Dowel pin
3.59 Cheese head screw
3.60 Spring washer
3.62 Cheese head screw
3.73 Set screw
3.76 Featherkey
3.78 Circlip
3.80 Seal
4.00 Spindle housing assembly
4.01 Spindle housing
4.02 Housing
4.03 Spindle
4.04 Guide part
4.05 Shaft
4.06 Ball headed pin
4.08 Socket
4.09 Adapter
4.10 Small worm−geared motor
4.12 Handwheel
4.13 Rotation−direction indicator
4.14 Setting indicator
4.15 Bevel
4.16 Bevel
4.17 Worm
4.20 Deep−groove ball bearing
4.21 Socket
4.22 Flange sleeve
4.23 Shaft sealing ring
4.24 Shaft sealing ring
4.25 Seal
4.26 Seal
4.27 Sealing ring
4.28 Circlip
4.29 Locking ring
4.31 Shim ring
4.32 Seeger ring
4.33 Dowel pin
4.34 Dowel pin
4.35 Dowel pin
4.36 Dowel pin
Pos. Name
4.37 Dowel pin
4.38 Dowel pin
4.39 Set screw
4.40 Set screw
4.41 Set screw
4.42 Conical plug
4.43 Protection cover
4.44 Hexagon head cap screw
Cheese head screw
4.45 Hexagon head cap screw
Cheese head screw
4.46 Spring washer
4.47 Cheese head screw
4.48 Circlip
4.51 Cover
4.52 Cheese head screw
4.53 Spring washer
4.55 Hub
4.56 Bell housing
4.57 Handle
4.58 Hexagon head cap screw
6.00 Inner sun assembly
6.01 Left inner sun
6.02 Right inner sun
6.03 Planet
6.04 Pressure disc
6.05 Disk spring
6.06 Circlip
201 Pinion
220 O−ring
221 Hexagon head cap screw
4401 Flange
4410 Shaft
4420 Deep−groove ball bearing
4421 Shaft sealing ring
4422 Circlip
4423 Deep−groove ball bearing
4424 Adapter disc
4425 Circlip
4471 Hexagon head cap screw
