Maintenance – Lenze DISCO−Variable speed drive User Manual
Page 26
Maintenance
Oil filling quantities for DISCO gearboxes
Breather position, oil filling screw and drain plug
l
26
BA 11.5032−EN 3.0
7.1.2
Breather position, oil filling screw and drain plug
GT−DISCO−007.cdr
Oil filling for gearboxes without ventilation
Ventilation / oil filler plug
Oil drain plug
Oil control plug
1)
Facing the housing
2)
In case of a position of the handle different from the shown one, the positions are facing the housing respectively
