Technical data
Transport weights
3
l
18 BA 11.5032−EN 3.0
3.2 Transport weights
DISCO with GST helical gearbox
Gearbox size Drive size
071−1 L 02 071−3 L 03 080−3 L 04 090−3 L 05 100−32 06 112−22 07 132−12 18 132−22 08
GST 04 < 18
GST 05 < 25 < 32 < 43
GST 06 < 36 < 40 < 51 < 67
GST 07 < 56 < 64 < 75 < 83 < 120 < 130
GST 09 < 99 < 110 < 127 < 150 < 161 < 223 < 230
GST 11 < 168 < 185 < 221 < 232 < 272 < 279
GST 14 < 296 < 333 < 343 < 406 < 413
DISCO with GKS helical−bevel gearbox
Gearbox size Drive size
071−1 L 02 071−3 L 03 080−3 L 04 090−3 L 05 100−32 06 112−22 07 132−12 18 132−22 08
GKS 04 < 28
GKS 05 < 41 < 49 < 59
GKS 06 < 64 < 69 < 79 < 96
GKS 07 < 104 < 113 < 123 < 131 < 168 < 178
GKS 09 < 191 < 202 < 218 < 242 < 252 < 315 < 322
GKS 11 < 329 < 346 < 382 < 392 < 433 < 440
GKS 14 < 574 < 607 < 621 < 684 < 709
DISCO with GSS helical−worm gearbox
Gearbox size Drive size
071−1 L 02 071−3 L 03 080−3 L 04 090−3 L 05 100−32 06 112−22 07
GSS 04 < 28
GSS 05 < 41 < 48 < 59
GSS 06 < 62 < 56 < 77 < 94
GSS 07 < 101 < 109 < 120 < 128 < 165 < 175
DISCO type 11.700 / 11.710
DISCO
size Type 11.700 with motor size Type
11.700
071−1 L 071−3L 080−1L 080−3L 090−1L 090−3L 100−1L 100−3L 112−22 132−12 132−22
02 < 10 < 5
03 < 19 < 13
04 < 27 < 28 < 21
05 < 42 < 45 < 35
06 < 74 < 78 < 58
07 < 89 < 58
09 < 151 < 88
11 < 158 < 85
Weight in [kg] with oil filling, for mounting position A, all values are aproximate
