Appendix 10
l
37 BA 11.5032−EN 3.0
Pos. Name
0.25 Seal
0.26 Seal
0.28 Hexagon head cap screw
0.29 Locking washer for sizes 02−03
Spring washer for sizes 04−07
0.30 Cheese head screw
0.31 Spring washer
0.40 Oil sight glass
0.41 Locking screw
0.42 Angled breather tube
1.01 Housing
1.02 Thrust collar
1.03 Foot
1.04 Set screw
1.05 Seal−Lock hexagon nut
1.06 Dowel pin
1.07 Cheese head screw
1.08 Oil sight glass
2.01 Cover
2.02 Shaft
2.04 Housing
2.05 Flange
2.06 Fan cover
2.07 Socket
2.08 Three−phase AC motor
2.09 Fan
2.10 Starting coupling
2.11 Flexible coupling
2.15 Deep−groove ball bearing
2.16 Deep−groove ball bearing
2.17 Inner ring
2.18 Shaft sealing ring
2.19 Circlip
2.20 Circlip
2.21 Circlip
2.22 Featherkey
2.23 Featherkey
2.24 Featherkey
2.25 Shim ring
2.27 Seal
2.28 Set screw
2.29 Set screw
2.30 Hexagon head cap screw
2.31 Locking washer for sizes 02−03
Spring washer for sizes 04−07
2.32 Cheese head screw
2.33 Seal
2.34 Cheese head screw
2.35 Spring washer
2.36 Hexagon head cap screw
2.37 Hexagon nut
2.38 Spring washer
Pos. Name
3.01 Cover
3.03 Flange
3.05 Shaft
3.08 Hub
3.09 Pinion cage
3.10 Slide block
3.11 Socket
3.12 Washer
3.14 Clutch collar
3.15 Ball retainer ring
3.16 Clutch thrust collar
3.17 Flange
3.19 Socket
3.26 Socket
3.27 Pressure spring
3.28 Deep−groove ball bearing
3.29 Deep−groove ball bearing
3.32 Deep−groove ball bearing
3.36 Shaft sealing ring
3.38 Circlip
3.39 Circlip
3.40 Circlip
3.41 Circlip
3.51 Circlip
3.52 Dowel pin
3.53 Hexagon head cap screw
3.56 Dowel pin
3.57 Dowel pin
3.58 Dowel pin
3.59 Cheese head screw
3.60 Spring washer
3.62 Cheese head screw
3.73 Set screw
3.76 Featherkey
3.78 Circlip
3.80 Seal
6.00 Inner sun assembly
6.01 Left inner sun
6.02 Right inner sun
6.03 Planet
6.04 Pressure disc
6.05 Disk spring
6.06 Circlip
201 Pinion
220 O−ring
221 Hexagon head cap screw
Pos. Name
4401 Flange
4410 Shaft
4420 Deep−groove ball bearing
4421 Shaft sealing ring
4422 Circlip
4423 Deep−groove ball bearing
4424 Adapter disc
4425 Circlip
4471 Hexagon head cap screw
