Electrical installation
Connecting the supply and peripheral devices
Ethernet interface (X107)
6
l
31 BA_CPCx8xx EN 3.0
6.3.7 Ethernet interface (X107)
Description Connection type Cable type
Ethernet connection
10/100 Mbps
Green LED (SPEED):
on = 100 MBPS
off = 10 Mbps
Yellow LED (LINK/ACTIVITY):
on or blinking = LINK
/ACTIVITY
off = no LINK
RJ45 socket
Network cable CAT5 S/UTP or
CAT5e S/FTP (recommended),
cable length: max. 100 m
IPC001
)
Note!
If the RJ45 plug connection is exposed to oscillating or vibrating stress:
ƒ Use a strain relief in the immediate vicinity of the RJ45 socket.
ƒ Select the contact surface on which the device is mounted as fixing point of
the strain relief.
ƒ Comply with the related minimum bending radius of the cable used.
6.3.8 USB interface (X104, X105, X106)
Description Connection type Cable type
USB 2.0 host connection
Max. load: 5 V/500 mA
USB−A socket USB cable with USB−A plug
IPC001
6.3.9 Communication interface (MC card)
Description Connection type Cable type
Interface for MC card Socket connector −
EL100−013
