Maintenance
Repair
Dismounting and mounting the PC
8
l
54 BA_CSx8xx EN 3.0
8.3 Repair
For corrective maintenance of the Command Station, the PC has to be removed and placed
on a clean, padded surface, flat and with the screen face down.
8.3.1 Dismounting and mounting the PC
(
Stop!
PC can fall down
If the PC is not screwed together with the mounting frame, it may fall down.
Possible consequences:
ƒ The PC and/or the screen are damaged.
ƒ Injuries caused by the falling device.
Protective measures:
ƒ Secure PC against falling down.
Dismounting

ƒ „
‚
0
0
2
1
+
3
4
}
}
max. 12 kg
}
}
CS57x0−013
0 Mounting frame
1 PC with screen
2 Attachment
3 PE connecting cable
4 Other connecting cables
