Leica Biosystems ASP300 - Manual (Page 32)

32 Instruction Manual V 1.3 – 12/2003
Fig. 14
→ →
• Remove the splash protector.
• Fill the wax bath ( Fig. 15 ) with wax pellets up
to the top.
• Press BACK and REAGENT STATUS to ac-
cess the reagent status table (
Fig. 14 ). High-
light the wax bath you just filled and press
SET AS FULL.
• After about 90 minutes, add another 0.5 kg
of wax pellets.
• The pellets will take a total of approx. 10
hours to melt.
Important!
During the melting process, the paraf-
fin level MAY NOT drop below the
MIN level (2,
Fig. 15 ).
• Once the paraffin is completely molten, re-
insert the splash protector.
Software control
• The software calculates when the wax will
be ready for use and selects program start-
ing times accordingly, i.e. the paraffin will
definitely be molten when it is required for
the first paraffin step.
Filling with wax pellets
5. Operation
Fig. 15
1
2
