Page 26: User interface - overview, Setting up the instrument
26
Instruction manual V 1.3 – 12/2003
4.7 Touch screen functions
4.7.1 User interface - overview
The Leica ASP300 is programmed and operated via a colored LCD
touch screen.
An on-line help feature provides detailed information on all instrument
functions.
HELP can be accessed from any screen by pressing the HELP button.
Button symbols
To activate any functions on the Leica ASP300 touchscreen, press the
corresponding button symbols. Examples of buttons are:
4.
Setting up the instrument
Buttons on the Leica ASP300 touch screen can either be enabled or dis-
abled.
A button that is disabled appears with a thinner border than a button
that is enabled.
Disabled
Enabled
