Components of the 821 – Landoll ICON 800 Series Earthmover User Manual
Page 24
Components of the 821
Push Off Wall and Frame pinned
together using an ICO0420 on
each side.
5000479 Grease Line
Push Off Cyl.
4001035
ICO2005
ICO2003
ICO2006
ICO2045
Chrome Pin
Brake flow divider
4001283
Safety stop
ICO2108
4001236 gate cyl.
ICO0218
ICO0501
IC
O0
21
2R
Plastic Bushing
4001414
IC
O2
08
9
Af
ter
#6
29
7
Gate Arm
ICO2002
9302231
9102043
