Landoll CPP7-03 through CPP12-03 Chisel Plow User Manual
Page 18
2-10
7D525
ASSEMBLY
Figure 2-10: 7’ and 9’ LED Warning Lights Layout
CPP7&9 ElectLayout
SMV
Amber
LED
Red
LED
Bolt,1/4-20 x 1-1/2
Nut,1/4-20
7 Pin Harness
U-Bolt,1/2-13
U-Bolt,3/8-16
Bolt,5/16-18 x 1
Flat W
asher
,5/16
Nut,3/8-16
SMV
Mount
Nut,5/16-18
Bolt,1/4-20 x 1-1/2
Nut,1/4-20
Light Module
Module
Mount
U-Bolt,3/8-16
Nut,1/2-13
Light
Bracket
Lamp
Harness
Nut,3/8-16
