PT PULVERIZER WARNING LIGHT INSTALLATION INSTRUCTION BOOKLET

PT 17, 18, 20 INSTALLATION

!

WARNING

Install light brackets:

1.

Position the inner light brackets for red lamps to be
within 48" of the center of the machine. Secure with
U-bolt and locknut. See Figure 1-3.

2.

Secure the outer light brackets with outer bearing
hanger U-bolt.

Install warning lamps and reflector brackets:

1.

Install the outer warning lamps (amber), lamp
shields, and reflector brackets to outer brackets with
¼-20 x 1-1/2” hex head cap screws and ¼”-20
flanged lock nuts.

2.

Install the inner warning lamps (red) and reflector
brackets to inner brackets with ¼”-20 x1-1/4” hex
head cap screws and ¼”-20 flanged lock nuts. Make
sure red lens is rear facing.

Install electrical wiring and module:

1.

Lay out the wishbone harness making sure the sides
marked left or right are correct.

2.

Starting at the center of the machine, thread the
harness ends through openings in the center frame
lift weldment and light brackets, ending at the outer
light bracket.

3.

Install the enhanced lighting module by fastening it
with #8 screws, flat washers, lock washers and nuts
(2 each) to the inside of the center frame lift
weldment plate.

4.

Lay out the tractor harness on the drawbar, making
connection at the lighting module.

5.

Secure the tractor harness to the hydraulic hose with
cable ties, making sure to leave enough slack at the
lift weldment to allow the machine to raise and lower.

6.

Secure the wishbone harness with cable ties and
make connection to module. Bundle any excess wire
and secure.

NOTE

Be sure the frame braces do not interfere with the inner
decal plates as the machine cycles.

7.

Raise the machine if not done previously.Adjust the
lamp angles so lamps are vertical with the drawbar
height adjusted to the transport height.

8.

Adjustment is provided to compensate for high
drawbar heights if used as a companion tool or lower
heights if towed directly behind a tractor.

9.

Tighten all hardware.

Install reflectors:

1.

The amber reflectors should be on the front of the
outer brackets, red and orange fluorescent reflectors
should be rear facing on all four brackets.

2.

Apply the remaining 2 amber reflectors to the outside
of each wheel arm. See Figure 1-1.

3.

Install SMV emblem to the bracket by fastening it with
2 - 5/16”-18 x 1” screws, flat washers and NY-LOK
nuts.

4.

Attach the bracket to the left side of the center
bearing hanger.

NOTE

Final assembly should have red lamps within 48" of the
center of the machine and amber lamps and reflectors
within 16" of machine extremity. As viewed from the rear,
there should be no more than 60" between red reflectors,
including the SMV emblem.

Lower machine to ground before removing any
hardware
