Row marker assembly – Landoll 4630-36 Folding Seeder Parts Manual v.F-641-0313 03/2013 User Manual
Page 30
2-24
F-641-0313 Edition
ILLUSTRATED PARTS LIST
ROW MARKER ASSEMBLY
ITEM
PART NO.
DESCRIPTION
QTY.
171633
ROW MARKER ASSEMBLY
1
1-298-010001-1
ZERK, FITTING 1/4
6
2
1-511-010001-07
NUT, HEX JAM 5/8-11
2
3
1-512-010005-03
NUT, HEX LOCK 5/16-18 GRB
8
4
1-512-010005-05
NUT, HEX LOCK 3/8-16 GRB
6
5
1-512-010005-09
NUT, HEX LOCK 1/2-13 GRB
2
6
1-512-010005-13
NUT, HEX LOCK 5/8-11 GRB
26
7
1-512-010007-06
NUT, HEX 5/16-18
8
8
1-512-010007-09
NUT, HEX 1/2-13
16
9
1-557-010362-40
PIN, COTTER 5/32 X 1-1/4
4
10
1-557-010362-63
PIN, COTTER 1/4 X 2
14
11
1-654-010049-05
SCREW, HEX HEAD CAP 5/16-18 X 1 GR5
8
12
1-654-010051-08
SCREW, HEX HEAD CAP 3/8-16 X 1-3/4 GR5
4
13
1-654-010051-11
SCREW, HEX HEAD CAP 3/8-16 X 2-1/2 GR5
2
14
1-654-010055-04
SCREW, HEX HEAD CAP 1/2-13 X 1-3/4 GR5
2
15
1-654-010059-05
SCREW, HEX HEAD CAP 5/8-11 X 2 GR5
16
16
1-654-010059-11
SCREW, HEX HEAD CAP 5/8-11 X 3 GR5
2
17
1-654-010070-11
SCREW, RD HEAD SQ NECK 1/2-13 X 3-1/2
4
18
1-861-010032-11
WASHER, FLAT 3/8W
8
19
1-861-010034-10
WASHER, SPLIT LOCK 5/16
8
20
1-861-010034-11
WASHER, SPLIT LOCK 3/8
2
21
1-861-010034-13
WASHER, SPLIT LOCK 1/2
24
22
102-0322
BULKHEAD
2
23
104031
SCREW, RD HEAD SQ NECK 5/16-18 X 1 GR5
8
24
104329
HOSE ASSEMBLY 3/8 X 312
2
25
111-2590
CLEVIS PIN 5/8 X 1-3/4
2
26
116032
PIN, WASHER ROWMARKER WELDMENT
2
27
116034
PIN, DOUBLE HOLE ROWMARKER PIVOT
4
28
116038
SHIPPING RETAINER, ROW MARKER HUB
2
29
116100
WASHER, FLAT 1-1/4N
12
30
116254
WASHER, MARKER MOUNT
4
31
116337
BLADE, SOLID 16” PLAIN
2
32
116339
YOKE, EXTERNAL THREADED PLAIN
2
33
116344
CYLINDER, MARKER 2-1/2 X 20 (SEE PAGE 2-51)
2
34
116350
VALVE ASSEMBLY
1
35
116354
TUBE 5/8 X 1-7/8
2
36
116355
PIN, 7/8 X 11
2
37
116366
RUBBER SPACER
2
38
116390
DEPTH BAND WELDMENT
2
39
116405
YOKE, INTERNAL THREADED CLEVIS
2
40
116438
PIN, 1-1/4 X 12-1/4
2
41
116446
LH SPINDLE AND HUB WELDMENT(NOT SHOWN) (ITEMS 69-78)
1
42
116447
RH SPINDLE AND HUB WELDMENT (ITEMS 69-78)
1
43
117186
ARMORITE BRACE CUSHION
2
44
119084
PIN, COTTER 1/4 X 1-1/4
4
45
120369
CHAIN, ROW MARKER
2
46
120400
CHAIN COVER, ROW MARKER
2
47
1410224
DECAL, PINCH POINT
2
48
141597
DECAL, DANGER ELECTROCUTION
2
