ILLUSTRATED PARTS LIST
2-5
20 1-861-010032-24 WASHER, FLAT 1"N 2
21 1-861-010034-13 WASHER, SPLIT LOCK 1/2 32
22 114616 SCREW, HEX HEAD CAP 1-8 X 8-1/2 GR5 1
23 140519 BEARING, UHMW 4" 3
24 141434 SAFETY CHAIN, 21,000 LB 1
161536 HOOK, SAFETY CHAIN 21,000 LB 1
25 143916 PLATE, SLIDE 8
26 144003 HUB AND SPINDLE ASSEMBLY, 8 BOLT (SEE PAGE 2-7) 4
27 144113 SPRING, COMPRESSION 8" 1
28 144138 VALVE, STOP 1
29 144355 PIN, 1 X 8 1
30 144356 PIN, 1-1/2 X 4-5/8 2
31 151533 SHIM, HITCH SLIDE 8
32 153696 BOLT, HITCH CLEVIS 1-8 X 7-1/2 2
33 153827 SHIM, LIFT BEARING 6
34 153859 PIN 1-1/2 X 10 1
35 167272 HITCH, SEEDER 36’ 1
36 167299 TIRE AND WHEEL ASSEMBLY 12.5 X 15 FI (INCL ITEMS 37-39) 4
37 167298 WHEEL, 15 X 10 LB 8 BOLT 3/8 1
38 2-798-010106 TIRE 12.5L X 15 1
39 TR416 VALVE STEM, TUBELESS TIRE 1
40 167310 CYLINDER, HYDRAULIC 3-1/2 X 6 (SEE PAGE 2-49) 1
41 167311 LIFT WELDMENT, CENTER 1
42 167314 CAP BEARING WELDMENT, LIFT 3
43 167315 LINK WELDMENT, TRANSPORT LOCK 2
44 167316 ROD WELDMENT, TRANSPORT LOCK 1
45 167317 BRACKET, TRANSPORT LOCK 1
46 167318 MOUNT, RELEASE VALVE 1
47 167319 COUPLER WELDMENT, TRANSPORT LOCK 1
48 167320 SLEEVE, TRANSPORT LOCK 1
49 167321 TUBE, TELESCOPING HITCH 1
50 167322 BRACKET, HOSE HOLDER 1
51 167323 JACKSTAND WELDMENT 1
52 167324 BRACKET, JACK STAND 2
53 2-150-010008 BUSHING, STEEL 6
54 2-181-010001 HOSE CLAMP 4
55 2-375-010602 HITCH RING, CAT IV 1
56 70239854 PIN, QUICK HITCH 2
57 70592442 PIN, SNAPPER 2
58 1-397-010369054 HOSE ASSEMBLY 3/8 X 54 (SEE PAGE 2-35) 1
59 71508988 HOSE ASSEMBLY 3/8 X 80 (SEE PAGE 2-35) 1
60 2062-8-8S ADAPTER, 90 2
MAIN HITCH FRAME ASSEMBLY
ITEM PART NO. DESCRIPTION QTY.
