Abmessungen

Typenschlüssel

(1)

(2)

703564/

.

-

. .

(1) Grundtypergänzung

1

Relaisausgänge 3 A, 230 V AC

2

Logikausgänge 12 V/20 mA

(2) Spannnungsversorgung

22

AC/DC 20 ... 53 V, 48 ... 63 Hz

23

AC 110 ... 240 V +10/-15%, 48 ... 63 Hz
