Data Sheet 902931 Page 4/10
Approvals/approval marks
Setup interface
- Baud rate
- PC interface 9600
With TTL/RS232 or with USB/TTL converter
RS485 interface
- Protocol
- Baud rate
- Device address
- Minimum response time Modbus
9600, 19200, 38400
1 to 254
0 to 500 ms
LCD display
Top line 4-digit 7-segment display, 4.5 mm high
Bottom line 5-digit 16-segment display, 4.0 mm high
Approval marks Testing agency Certificates/certification
numbers Inspection basis Valid for
c UL us Underwriters Laboratories E201387 UL 61010-1
CAN/CSA-C22.2 No. 61010-1 915 MHz, 230 V,
Basic type 902931/10
IC Industry Canada 7472A-WTRANST01
7472A-WTRANST0102
RSS-210 Issue 7
RSS-210 Issue 8
RSS-GEN Issue 3
RSS-102 Issue 4
915 MHz, 230 V,
Basic type 902931/10
FCC Federal Communications
Commission VT4-WTRANST01
VT4-WTRANST01-02
FCC Rule Part 15C
FCC Rule Part 15C
915 MHz, 230 V,
Basic type 902931/10
