Important probe information in the following tables
The following should be noted:
A save galvanic isolation between sensor and the case does not exist. As a result, the sensor connections are to be considered ground-
ed for the safety assessment.
Among other things the EN 60079-0 requires of the EPL Ga that the mass fraction of aluminum must be less than 10 % for the produc-
tion of metallic casing. The terminal head of the probes used by JUMO contains more than 10 % aluminum. Therefore the terminal
head for the use of EPL Ga (zone 0) must be secured by a suitable impact protection. The impact protection must securely prevent fric-
tion sparks, contact-breaking sparks, and impact sparks. Otherwise the risk of ignitable sparks exists.
No other precautions have to be taken when used in EPL Gb (zone 1).
DIN-approved probes for the operating-medium air
Note: because of the high response accuracy, the use of thermowells (immersion sleeves) is not admissible.
Current type designation Probe type Temperature range Nom. length mm Process connection
RTD temperature probe data sheet 902006
902006/65-228-1003-1-15-500-668/922 1 × Pt100 -170 to +700 °C 500
902006/65-228-1003-1-15-710-668/922 710
902006/65-228-1003-1-15-1000-668/922 1000
902006/55-228-1003-1-15-500-254/922 1 × Pt100 -170 to +700 °C 500
902006/55-228-1003-1-15-710-254/922 710
902006/55-228-1003-1-15-1000-254/922 1000
902006/65-228-2003-1-15-500-668/922 2 × Pt100 -170 to +700 °C 500 Stop flange
displaceable
902006/65-228-2003-1-15-710-668/922 710
902006/65-228-2003-1-15-1000-668/922 1000
902006/55-228-2003-1-15-500-254/922 2 × Pt100 -170 to +700 °C 500 Displaceable
screw connection G1/2
902006/55-228-2003-1-15-710-254/922 710
902006/55-228-2003-1-15-1000-254/922 1000
Thermocouples data sheet 901006
901006/65-547-2043-15-500-668/922 2 × NiCr-Ni, type "K" -35 to +800 °C 500 Stop flange
displaceable
901006/65-547-2043-15-710-668/922 710
901006/65-547-2043-15-1000-668/922 1000
901006/65-546-2042-15-500-668/922 2 × Fe-CuNi, type "L" -35 to +700 °C 500
901006/65-546-2042-15-710-668/922 710
901006/65-546-2042-15-1000-668/922 1000
901006/66-550-2043-6-500-668/922 2 × NiCr-Ni, type "K" -35 to +1000 °C 500
901006/66-550-2043-6-355-668/922 355
901006/66-550-2043-6-250-668/922 250
901006/66-880-1044-6-250-668/922 1 × PT10Rh-PT, type "S" 0 to 1300 °C 250
901006/66-880-1044-6-355-668/922 355
901006/66-880-1044-6-500-668/922 500
901006/66-880-2044-6-250-668/922 2 × PT10Rh-PT, type "S" 0 to 1300 °C 250 Stop flange
displaceable
901006/66-880-2044-6-355-668/922 355
901006/66-880-2044-6-500-668/922 500
901006/66-953-1046-6-250-668/922 1 × PT30Rh-PT6Rh, type "B" 600 to 1500 °C 250
901006/66-953-1046-6-355-668/922 355
901006/66-953-1046-6-500-668/922 500
901006/66-953-2046-6-250-668/922 2 × PT30Rh-PT6Rh, type "B" 600 to 1500 °C 250
901006/66-953-2046-6-355-668/922 355
901006/66-953-2046-6-500-668/922 500
Current type designation Probe type Temperature range Nom. length mm Process connection
