Environmental influences
Case
Approvals/approval marks
Ambient temperature range 0 to +55 °C
Storage temperature range -30 to +70 °C
Temperature influence ≤ ± 0.005 %/K dev. from 23 ×C 1 for RTD temperature probes
≤
± 0.01%/K dev. from 23×C
1
for thermocouples and current
Resistance to climatic conditions 85 % rel. humidity without condensation
(3K3 with extended temperature range according to DIN EN 60721-3-3)
EMC According to DIN EN 14597 and standards from the standard series DIN EN 61326
Interference emission Class B
Interference immunity Evaluation criteria FS according to DIN EN 14597, regulation and control devices (RS)
1. All specifications refer to the measuring range end value
Material Polycarbonate
Flammability class UL 94 V0
Electrical connection On the front via screw terminals up to 2.5 mm 2
Mounting On 35 mm DIN rail acc. to EN 60715
Installation position Any
Weight Approx. 230 g
Protection type IP 20 according to DIN EN 60529
Approval marks Testing agency Certificate / certification
numbers Inspection basis Valid for
DIN DIN CERTCO STB/STW 1228 DIN EN 14597 All device versions
SIL2, SIL3 TÜV Nord (German
Technical Inspection
Agency) SAS-0190/2006-3, V2.0 DIN EN 61508 All device versions
PL e DIN EN ISO 13849 All device versions
GL Germanischer Lloyd Testing submitted All device versions
Pressure Equipment Di-
rective TÜV Nord (German
Technical Inspection
Agency) 07 202 4834 Z 5077/3/H Pressure Equipment Directive
97/23/EG All device versions
ATEX TÜV Nord (German
Technical Inspection
Agency) TÜV 11 ATEX 556139 X Directive 94/9/EG All device versions
