JUMO 14597 safetyM TB/TW08 Temperature Limiter and Temperature Monitor Data Sheet - Manual (Page 8)

2012-07-01/00524703
Data sheet 70.1170 JUMO GmbH & Co. KG • 36035 Fulda, Germany Page 8/10
Probes for air
Probes for water and oil
Note: Because of the high response accuracy, the use of thermowells (pockets) is not admissible.
Actual type designation Old type
designation Probe type Temperature range Nom. length mm P rocess connection
RTD temperature probe Data Sheet 90.2006
902006/65-228-1003-1-15-500-668/000 - 1 x Pt100 -170 ... +700°C 500
902006/65-228-1003-1-15-710-668/000 - 710
902006/65-228-1003-1-15-1000-668/000 - 1000
902006/55-228-1003-1-15-500-254/000 - 1 x Pt100 -170 ... +700°C 500
902006/55-228-1003-1-15-710-254/000 - 710
902006/55-228-1003-1-15-1000-254/000 - 1000
902006/65-228-2003-1-15-500-668/000 90.271-F01 2 x Pt100 -170 ... +700°C 500 Stop flange,
movable
902006/65-228-2003-1-15-710-668/000 90.272-F01 710
902006/65-228-2003-1-15-1000-668/000 90.273-F01 1000
902006/55-228-2003-1-15-500-254/000 - 2 x Pt100 -170 ... +700°C 500 movable
G1/2 compression
clamp
902006/55-228-2003-1-15-710-254/000 - 710
902006/55-228-2003-1-15-1000-254/000 - 1000
Thermocouples Data Sheet 90.1006
901006/65-547-2043-15-500-668/000 90.019-F01 2 x NiCr-Ni, Typ E „K“ -35 ... +800°C 500 Stop flange,
movable 901006/65-547-2043-15-710-668/000 90.020-F01 710
901006/65-547-2043-15-1000-668/000 90.021-F01 1000
901006/65-546-2042-15-500-668/000 90.019-F11 2 x Fe-CuNi, Typ E „L“ -35 ... +700°C 500
901006/65-546-2042-15-710-668/000 90.020-F11 710
901006/65-546-2042-15-1000-668/000 90.021-F11 1000
901006/66-550-2043-6-500-668/000 90.023-F01 2 x NiCr-Ni, Typ E „K“ -35 ... +1000°C 500
901006/66-550-2043-6-355-668/000 90.023-F02 355
901006/66-550-2043-6-250-668/000 90.023-F03 250
901006/66-880-1044-6-250-668/000 90.021 1 x PT10Rh-PT, Typ E „S“ 0 ... 1300°C 250
901006/66-880-1044-6-355-668/000 90.022 355
901006/66-880-1044-6-500-668/000 90.023 500
901006/66-880-2044-6-250-668/000 90-D-021 2 x PT10Rh-PT, Typ E „S“ 0 ... 1300°C 250 Stop flange,
movable 901006/66-880-2044-6-355-668/000 90-D-022 355
901006/66-880-2044-6-500-668/000 90-D-023 500
901006/66-953-1046-6-250-668/000 90.027 1 x PT30Rh-PT6Rh, Typ E „B“ 600 ... 1500°C 250
901006/66-953-1046-6-355-668/000 90.028 355
901006/66-953-1046-6-500-668/000 90.029 500
901006/66-953-2046-6-250-668/000 90-D-027 2 x PT30Rh-PT6Rh, Typ E „B“ 600 ... 1500°C 250
901006/66-953-2046-6-355-668/000 90-D-028 355
901006/66-953-2046-6-500-668/000 90-D-029 500
Note: Because of the high response accuracy, the use of thermowells (pockets) is not admissible.
Actual type designation Old type
designation Probe type Temperature range Nom. length mm P rocess connection
RTD temperature probe Data Sheet 90.2006
90.2006/10-402-1003-1-9-100-104/000 1 x Pt100 -40 ... +400°C 100 G1/2 screw connection
90.2006/10-402-2003-1-9-100-104/000 2 x Pt100 100
902006/54-227-2003-1-15-710-254/000 90.272-F02 2 x Pt100 -170 ... 550°C 65...670 movable
G1/2 compression clamp
902006/54-227-1003-1-15-710-254/000 90.272-F03 1 x Pt100 65...670
902006/10-226-1003-1-9-250-104/000 90.239 1 x Pt100 -170 ... 480°C 250 G1/2 screw connection
902006/10-226-2003-1-9-250-104/000 90-D-239 2 x Pt100 250
Thermocouples Data Sheet 90.1006
901006/54-544-2043-15-710-254/000 90.020-F02 2 x NiCr-Ni, Type „K“ -35 ... 550°C 65...670 movable
G1/2 compression clamp
901006/54-544-1043-15-710-254/000 90.020-F03 1 x NiCr-Ni, Type „K“ 65...670
901006/54-544-2042-15-710-254/000 90.020-F12 2 x FeCuNi, Type „L“ 65...670
901006/54-544-1042-15-710-254/000 90.020-F13 1 x FeCuNi, Type „L“ 65...670
