Data Sheet 603021
JUMO GmbH & Co. KG
Delivery address: Mackenrodtstraße 14
36039 Fulda, Germany
Postal address: 36035 Fulda, Germany
Phone: +49 661 6003-0
Fax: +49 661 6003-607
E-mail: [email protected]
Internet: www.jumo.net
JUMO Instrument Co. Ltd.
JUMO House
Temple Bank, Riverway
Harlow, Essex CM20 2DY, UK
Phone: +44 1279 635533
Fax:
+44 1279 635262
E-mail: [email protected]
Internet: www.jumo.co.uk
JUMO Process Control, Inc.
6733 Myers Road
East Syracuse, NY 13057, USA
Phone: 315-437-5866
1-800-554-5866
Fax: 315-437-5860
E-mail: [email protected]
Internet: www.jumousa.com
2014-01-08/00073225
Page 9/10
Order details
(Please observe our stock versions and specify the parts no.)
Surface-mounted thermostat, ATH series
Order code (1) Basic type
603021 Surface-mounted thermostat, ATH series
(2) Basic type extensions
01 ATH-1 Temperature controller (TR)
02 ATH-2 Temperature monitor (TW)
20 ATH-20 Safety temperature monitor STW (STB)
70 ATH-70 Safety temperature limiter (STB)
(3) Design type
1 ATHs with rigid thermowell
2 ATHf with capillary
(4) Control ranges / limit value ranges °C
014 -20 to + 0 50 (only for TR and TW)
016 -10 to + 0 40 (only for TR and TW)
021 +0 0 to + 0 50
025 +0 0 to +100
041 +20 to + 0 90
042 +20 to +120
043 +20 to +150
045 +20 to +400
046 +20 to +500
052 +30 to +110
062 +50 to +200
063 +50 to +250
064 +50 to +300
066 +60 to +130
(5) Switching differential
00 Without switching differential (-70 STB)
15 1.5% of the scale range (only for TR + TW)
20 2 % of the scale range (only for STW (STB))
30 3 % of the scale range (only for TR + TW)
50 5 % of the scale range (only for TR + TW + STW (STB))
60 6 % of the scale range (only for TR + TW)
70 7 % of the scale range (only for STW (STB))
90 9 % of the scale range (only for STW (STB))
(6) Capillary length
0 ATHs without capillary
1000 1000 mm
2000 2000 mm
3000 3000 mm
4000 4000 mm
5000 5000 mm
.... (Special length, specifications in plain text)
(7) Capillary material
00 ATHs without capillary
40 Cu (Copper)
20 CrNi (Stainless steel)
