Stock versions with rigid thermowell
Temperature monitor (TW)
(delivery within 3 working days after receipt of order)
Safety temperature monitor STW (STB)
(delivery within 3 working days after receipt of order)
Part no. Type
Control range / limit value
range
°C
Switching
differential
%
Process connection
screw-in sleeve
Immersion tube Ш Ч length
mm
60001135 ATHs-2 –10 to + 40 3-4
"20" G 1 /
2
8 x 200
60001549 ATHs-2 +2 0 to + 50 1.5 15 x 100 CrNi
60001128 ATHs-2 +2 0 to + 50 3-4 8 x 200
60000177 ATHs-2 +20 to + 90 1.5 15x100
60000959 ATHs-2 +20 to + 90 6-8 15x100
60001129 ATHs-2 +20 to + 90 3-4 8x150
60000331 ATHs-2 +2 0 to +100 3-4 8x120
60001552 ATHs-2 +2 0 to +100 3-4 8x120 CrNi
60000179 ATHs-2 +2 0 to +100 3-4 8x150
60001039 ATHs-2 +2 0 to +100 3-4 8 x 200
60001130 ATHs-2 +2 0 to +100 3-4 8x300
60000483 ATHs-2 +20 to +150 3-4 8x100
60001551 ATHs-2 +20 to +150 3-4 8x100 CrNi
60000485 ATHs-2 +20 to +150 3-4 8 x 200
60001554 ATHs-2 +20 to +150 3-4 8x200 CrNi
60000182 ATHs-2 +20 to +150 3-4 8x300
60003319 ATHs-2 +50 to +200 3-4
"30" G 1 /
2
8x120 CrNi
60003320 ATHs-2 +50 to +200 3-4 8x200 CrNi
60001556 ATHs-2 +50 to +300 3-4 8x150 CrNi
60003322 ATHs-2 +20 to +500 5 8x200 CrNi
Part no. Type
Control range / limit value
range
°C
Switching
differential
%
Process connection
screw-in sleeve/
weld-in sleeve
Immersion tube Ш Ч length
mm
60001478 ATHs-20 +20 to +150 4-6 "20" G 1 /
2
8x150
60003323 ATHs-20 +50 to +300 5 "30" G
1
/
2
8x200 CrNi
60002217 ATHs-20 +50 to +350 4-6 "46" G 3 /
4
170 steel, conical
60003324 ATHs-20 +20 to +500 7 "31" G 1 /
2
8x200 CrNi
