Data Sheet 70.6560
JUMO GmbH & Co. KG • 36035 Fulda, Germany
Page 4/12
Screen
Electrical data
Environmental influences
Housing
External analog measurement inputs / binary inputs / binary outputs
Approvals/marks of conformity
Resolution
320 x 240 pixels
Size
5.7"
Number of colors
27 colors
Supply (switch-mode power supply)
110 — 240V AC +10/-15%, 48 — 63Hz or 20 — 30V AC/DC 48 — 63Hz
Electrical safety
Test voltages (type test)
- mains supply circuit to
measurement circuit
- mains supply circuit to housing
(protective earth)
- measurement circuits to
measurement circuit and housing
- electrical isolation between the
analog inputs
to EN 61 010, Part 1, August 2002
overvoltage category II, pollution degree 2
with AC supply: 3.7kV 50Hz, 1min,
with AC/DC supply: 510V 50Hz, 1min
with AC supply: 2.3kV 50Hz, 1min,
with AC/DC supply: 510V 50Hz, 1min
510V 50Hz, 1min
up to 30V AC and 50V DC
Supply voltage error
less than 0.1% of span
Power consumption
25VA approx.
Data backup
see page 7
Electrical connection
at rear through plug-in screw terminals,
max. conductor cross-section 2.5mm
2
or 2x 1.5mm
2
with ferrules
Ambient temperature range
0 to +45°C
Ambient temperature error
0.03% per °C
Storage temperature range
-20 to +60°C
Climatic conditions
not exceeding 75% relative humidity, no condensation
Electromagnetic compatibility
(EMC)
- interference emission
- immunity to interference
EN 61 326-1
Class A - only for industrial use -
to industrial requirements
Housing front
zinc die-casting
Housing type
housing for flush-panel mounting to IEC 61 554, galvanized steel
Bezel size
200mm x 144mm
Depth behind panel
233mm
Panel cut-out
138
+1.0
mm x 138
+1.0
mm
Housing fixing
in panel to DIN 43 834
Operating position
unrestricted, taking into account the viewing angle of the screen,
horizontal ±50°, vertical ±30°
Protection
to EN 60 529 Category 2,
front IP54 (IP65 with extra code stainless steel front),
rear IP20
Weight
3.5kg approx.
Type
JUMO mTRON automation system
Sampling cycle
1sec
Technical data
see Data Sheet:
70.4015 Relay module, 70.4020 Analog input module, 70.4030 Logic module
Configuration
iTOOL Project design software (70.4090)
Mark of
conformity
Testing
laboratory
Certificates /
certification numbers
Test basis
valid for
c UL us
Underwriters
Laboratories
E 201387
UL 61010B-1
CAN/CSA-C22.2 No. 1010.1-92
the flush-mounted instrument;
not in conjunction with extra
code 350
