Data Sheet 70.6560 JUMO GmbH & Co. KG • 36035 Fulda, Germany Page 2/12
Technical data
Internal analog inputs (channels 1 to 12)
Thermocouple
Resistance thermometers
Designation Type Standard Range Linearization accuracy
1
Fe-Con L DIN 43 710
Fe-Con J EN 60 584
Cu-Con U DIN 43 710
Cu-Con T EN 60 584
NiCr-Ni K EN 60 584
NiCr-Con E EN 60 584
NiCrSi-NiSi N EN 60 584
Pt10Rh-Pt S EN 60 584
Pt13Rh-Pt R EN 60 584
Pt30Rh-Pt6Rh B EN 60 584
-200 to + 900°C
-210 to +1200°C
-200 to + 600°C
-270 to + 400°C
-270 to +1372°C
-270 to +1000°C
-270 to +1300°C
-50 to +1768°C
-50 to +1768°C
0 to 1820°C
±0.1%
±0.1% above -100°C
±0.1% above -150°C
±0.15% above -150°C
±0.1% above -80°C
±0.1% above -80°C
±0.1% above -80°C
±0.15% above
0°C
±0.15% above 0°C
±0.15% above 400°C
Shortest span Types L, J, U, T, K, E, N:
Types S, R, B: 100°C
500°C
Range start/end freely progammable within the limits in 0.1 °C steps
Cold junction Pt100 internal or thermostat external constant
Cold junction accuracy (internal) ± 1°C
Cold junction temperature (external) -50 to +100°C, adjustable through setup software
Sampling cycle 6 or 12 channels 125msec
Input filter 2nd order digital filter; filter constant adjustable from 0 — 10.0sec
Test voltage 500V (across optocoupler)
Resolution better than 14 bit
Features also programmable in °F
1 The linearization accuracy refers to the maximum range span.
The linearization accuracy is reduced for shorter spans.
Designation Standard Connection Range Linearization accuracy Measuring
current
Pt 100 EN 60 751 2/3-wire
2/3-wire
4-wire
4-wire -200 to +500°C
-200 to +850°C
-200 to +500°C
-200 to +850°C ±0.4°C
±0.8°C
±0.4°C
±0.5°C 500
μ
A
250
μ
A
500
μ
A
250
μ
A
Pt 100 JIS 2/3-wire
2/3-wire
4-wire
4-wire -200 to +500°C
-200 to +650°C
-200 to +500°C
-200 to +650°C ±0.4°C
±0.8°C
±0.4°C
±0.5°C 500
μ
A
250
μ
A
500
μ
A
250
μ
A
Pt 500 EN 60 751 2/3-wire
2/3-wire
4-wire
4-wire -200 to +500°C
-200 to +850°C
-200 to +500°C
-200 to +850°C ±0.4°C
±0.8°C
±0.4°C
±0.5°C 250
μ
A
250
μ
A
250
μ
A
250
μ
A
Pt 1000 EN 60 751 2/3-wire
2/3-wire
4-wire
4-wire -200 to +500°C
-200 to +850°C
-200 to +500°C
-200 to +850°C ±0.4°C
±0.8°C
±0.4°C
±0.5°C 500
μ
A
250
μ
A
500
μ
A
250
μ
A
Ni 100 EN 43760 2/3-wire
4-wire -60 to +180°C
-60 to +180°C ±0.4°C
±0.4°C 500
μ
A
500
μ
A
Connection type 2-, 3- or 4-wire circuit
Shortest span 15°C
Probe lead resistance max. 30
Ω
per core for 3- and 4-wire circuit
max. 10
Ω
per core for 2-wire circuit
Range start/end freely programmable within the limits in 0.1°C steps
Sampling cycle 6 or 12 channels 125msec
Input filter 2nd order digital filter; filter constant adjustable from 0 — 10sec
Test voltage 500V (across optocoupler)
Resolution better than 14 bit
Features also programmable in °F
