JUMO GmbH & Co. KG • 36035 Fulda, Germany
2009-11-01/00389005
Data Sheet 70.9050 Seite 7/12
Actual value output 0 ... 10V (U
2
, P, I
2
)
I
max
approx. 2mA
10 +
6 ground
Resistance output 0 ... 5V (R)
I
max
approx. 2mA
8 +
6 ground
Connection for Screw terminal X103 Detail
Load fault output with relay
contact rating 230V AC/3A
resistive load
relay drops out at fault 1 make contact
2 break contact
3 common
Load fault output with
optocoupler Ic
max
= 2mA
U
CEO max
= 32 V
3 collector
1 emitter
8
6
+
–
Wiring for single-phase mode phase / N with
type 709050/X1...
Wiring for single-phase mode phase / phase with
type 709050/X1...
