JUMO GmbH & Co. KG • 36035 Fulda, Germany
2009-11-01/00389005
Data Sheet 70.9050
Seite 4/12
General characteristics
Chokes
EMC filter
Fault signal output
Type 709050/X1...
Type 709050/X2...
Type 709050/X3...
Relay (changeover contact)
without contact suppression
150000 switching actions at switched power level of 3A/230V 50Hz resistive load
Optocoupler output
I
Cmax
= 2mA, U
CEOmax
= 32V
Dimensions of the power converter
(length x width x height)
(272 x 260 x 175) mm
(348.6 x 300 x 217) mm
(403.5 x 300 x 257.5) mm
Weight
approx. 9 kgs
approx. 17 kgs
approx. 22.5 kgs
Type
Dimensions
Abutting
cross section
Connection,
tightening torque
Weight
Sales
number
L = 0.6 mH / I
N
= 75A
protection IP 10 as per EN 60529
Choke diameter: 155 mm
Height: 135 mm
Diameter of fixing
hole: 10.4 mm
4...25 mm
2
Via screw terminals,
max. 4...4.5 Nm
approx.
7.5 kgs
70/00392474
L = 0.6 mH / I
N
= 100A
protection IP 10 as per EN 60529
Height: 208 mm
Width: 200 x 200 mm
10...50 mm
2
Via screw terminals,
max. 6...8 Nm
approx.
20 kgs
70/00415759
L = 0.6 mH / I
N
= 200A
protection IP 10 as per EN 60529
Height: 190 mm
Width: 200 x 385 mm
35...95mm
2
Via screw terminals,
max. 15...20 Nm
approx.
37 kgs
70/00436848
For voltage supply to power section
Nominal voltage,
Nominal current
Dimensions
(length x width x
height)
Abutting
cross section
tightening
torque
Weight
Permissible
ambient
temperature
Sales No.
115V/250V/440V AC,
I
Nom
= 16A
(255 x 60 x 125) mm
0.25...4 mm
2
0,6 ... 0.8 Nm
approx. 4 kgs
40°C
70/00399527
115V/250V/440V AC,
I
Nom
= 20A
(289 x 70 x 140) mm
0.5...10 mm
2
1,5 ... 1.8 Nm
approx. 5.5 kgs 40°C
70/00438775
115V/250V/440V AC,
I
Nom
= 32A
(324 x 90 x 160) mm
0.5...10 mm
2
1,5 ... 1.8 Nm
approx. 9.5 kgs 40°C
70/00409831
115V/250V/440V AC,
I
Nom
= 63A
(380 x 117 x 190) mm
0.5...16 mm
2
2 ... 2.3 Nm
approx. 17 kgs
40°C
70/00409990
115V/250V/440V AC,
I
Nom
= 100A
(445 x 150 x 220) mm
10...50 mm
2
6 ... 8 Nm
approx. 26 kgs
40°C
70/00431997
For voltage supply to the control section
115V/250V AC,
I
Nom
= 1A
(80 x 45 x 30) mm
via
spade connec-
tor
6,3 x 0,8mm
-
approx. 120 kgs 40°C
70/00413620
