41

8 Appendix

8.1

Technical data

8.1.1

Outputs

8.1.2

Electrical data

8.1.3

Case and ambient conditions

4 relay outputs (changeover contact)

Switching capacity

3 A at AC 230 V resistive load

3 A at DC 30 V resistive load

Contact life

350,000 operations at rated load / 750,000 operations at 1 A

Voltage supply

Connection

Lateral (feed via base unit or router module)

Voltage

DC 24 V +25/-20 %

Residual ripple

5 %

Current consumption

120 mA (at DC 19.2 V)

Power consumption

3 W

Relay outputs

Connection

At the front (removable terminal strips with Push-In technology)

Conductor cross section

Wire or strand without ferrule

Min. 0.5 mm

2

, max. 2.5 mm

2

Strand with ferrule

Min. 0.5 mm

2

, max. 2.5 mm

2

2 x strand with twin ferrule

with plastic collar

Min. 0.5 mm

2

, max. 1.5 mm

2

(both strands with the same cross sec-

tion)

Stripping length

10 mm

Electrical safety

Acc. to EN 61010-1

Overvoltage category III, pollution degree 2

Electromagnetic compatibility

Acc. to EN 61326-1

Interference emission

Class A – only for industrial use –

Interference immunity

To industrial requirements

Case type

Plastic case for DIN rail mounting in the control cabinet (indoor use);
DIN rail acc. to DIN EN 60715, 35 mm x 7.5 mm x 1 mm

Dimensions (W x H x D)

22.5 mm x 103.6 mm x 101.5 mm (without connection elements)

Weight

Approx. 160 g

Protection type

IP20, acc. to DIN EN 60529

Ambient temperature range

-20 to +55 °C

Storage temperature range

-40 to +70 °C

Resistance to climatic conditions

Relative humidity

90 % annual average without condensation (cli-

matic class 3K3 acc. to DIN EN 60721-3-3 with extended tempera-
ture and humidity range)

Site altitude

Up to 2000 m above sea level

Mechanical ambient conditions

1

Classification acc. to DIN EN 60721-3-3, table 6, class 3M2

1

Test conditions are listed in the System Descripton B 705000.8.
