31

6 Configuration

6.1

Digital outputs

Four digital outputs (relay 1 to 4) are available.
The digital outputs are exclusively driven by external inputs (NV_Relay01 to NV_Relay04).

Chapter 6.2 "NV connecting list", page 32

Setup dialog

Parameter

Status after change of configuration

Modified parameters are incorporated immediately.

Behavior after power on

During the initialization phase of the relay module, the digital outputs are inactive (relays in idle
position).

TIP!
The parameters described in this section can be configured either with the setup program or
on the multifunction panel.

Parameter

Selection/settings

Description

Relay 1 to

Relay 4

Assign a TAG number

Identification marking (documentation in
PLC)
