6 Configuration

34

Binary linking

Binary linking 1 to 8

Result of binary linking 1 to 8

PLC Binary output 9 to 32

Signal of PLC digital output 9 to 32

Binary PLC out-
put block 13 to
block 18

PLC Binary output 1 to 32

Signal of PLC digital output 1 to 32

Alarm analog
variables

Alarm1 ExAI1 to Alarm1 ExAI64

Alarm signal 1 of analog variable 1 to 64

Alarm2 ExAI1 to Alarm2ExAI64

Alarm signal 2 of analog variable 1 to 64

Alarm integer
variables

Alarm1 ExInt1 to Alarm1 ExInt64 Alarm signal 1 of integer variable 1 to 64

Alarm2 ExInt1 to Alarm2ExInt64

Alarm signal 2 of integer variable 1 to 64

Category

Signal

Description
