33

6 Configuration

Status after change of configuration

The connections are available immediately.

Behavior after power on

The connections are available immediately after system initialization.

6.2.1

Digital signals

The following table contains all signals that are available in the NV connecting list for connec-
tion to the external inputs (NV_...) of the relay module.

Category

Signal

Description

Inactive

No signal selected

Central processing unit

Digital variables

Digital variable 1 to 64

Digital variable 1 to 64 (via interface)

Program

generator 1 to

Program

generator 9

Operating contact 1 to 16

Operating contact 1 to 16 of program channels
(in the three program channels, operating con-
tacts with the same name are linked with OR)

Mode: Basic status

Status: Program is not running (basic status)

Mode: Automatic

Status: Program is running (automatic mode,
no delay time or program end time)

Mode: Automatic 1

Status: Program is running (automatic mode,
incl. delay time and program end time)

Mode: Standstill

Status: Program stopped during automatic
mode (time base stopped)

Mode: Delay

Status: Program start delayed (delay time
runs)

Mode: Program end

Status: Program ends (program end time runs,
corresponds to length of end signal)

Mode: Manual

Status: Manual mode

Tolerance band channel 1 to 3

Tolerance band signal of program channel 1 to
3

PLC Binary output 27 to 32

Signal of PLC digital output 27 to 32

Limit monitoring

Limit monitoring 1 to 64

Output signal of limit value monitoring 1 to 64
