51

7 Online parameters

7.1.3

LED test

Setup dialog

Parameter

Parameter

Selection/settings

Description

S LED

To test the LED, click the required status
to select it (OFF, red, or green).
After selection, the LED enters the cho-
sen status immediately.

This function is used to test the electrical
function of the "S" LED (Status).

1 LED

To test the LED, click the required status
(OFF or yellow) to select it.
After selection, the LED enters the cho-
sen status immediately.

This function is used to test the electrical
function of LED "1".

TIP!
An LED maintains the set status until a new status is set or until the "LED test" dialog window
is closed.
