31
6 Configuration
6.1 Digital selector
The digital selector contains all digital signals that are available in the analog input module 8-
channel to configure the following functions.
•
Alarm suppression (see Chapter 6.2.1 "Alarms", page 34)
• Signal suppression (see Chapter 6.3 "Digital input", page 38)
The following table lists all digital signals. The entry in the "Type" column indicates the source
of the signal:
•
Internal: Internal signal of the analog input module 8-channel (including the signal of the dig-
ital input)The signal is also transmitted to the base unit via the system bus, to allow it to be
used by other modules.
• External: External input (NV_...) that must be linked in the NV connecting list to a signal
from another module (see Chapter 6.4 "NV connecting list", page 40).
The signal name "NV_..." indicates the intended use; in principle, the signal can also be
used for other purposes.
Alarm
The collective alarm of the analog input module 8-channel is made up of all functions for which
the "Collective alarm" alarm type has been activated.
TIP!
The parameters described in this section can be configured either with the setup program or
on the multifunction panel.
Category Signal Type Description
Inactive No signal selected
Analog inputs AI01Alarm1 to AI08Alarm1 Internal Alarm signal 1 of analog input 1 to
8
AI01Alarm2 to AI08Alarm2 Internal Alarm signal 2 of analog input 1 to
8
Digital inputs DI01 Internal Signal of digital input
Signal rejections NV_SR01 to NV_SR09 External Signal for activating signal sup-
pression
Alarm CollectiveAlarm Internal Module collective alarm
?
