Operating procedures

36

6. Operating

procedures

6.1. Switching on / Selecting the language

JULABO
P R E S T O

V1.45-1

Switching on:

 The unit is operated by pressing the mains power switch (1).

The integrated pilot lamp illuminates.

During the self-test all segments of the VFD-Info-Display, all
control indicators and the DIALOG-DISPLAY light up.
Then the software version number (example: V1.45-1)
appears for a short moment and the message "OFF" indicates
the unit is ready to operate.

Message >WAIT< when adjusting >Mode: sys close<:.
During the message >WAIT< the ventilation valve is opened for
10 seconds. So, the air which has eventually been collected
during the standstill, can escape.

The unit returns to the previous operating mode that was
active before it was turned off:
keypad control mode

(manual operation via the unit itself/RD)

or
remote control mode

(operation via PC).


Selecting the language:

There are two options for the language of the DIALOG-DISPLAY
(LCD): German or English. Select the desired language in the
MENU level under the submenu >Configuration.

Soll: 20.00°C
IntIst xxx.00°C
ExtIst:
Regelung:

>Konfiguration
Regelparameter

Konfiguration
Identif. xxxxx
Sollwert xxxxx
Autostart xxx
Standby xxxx
>Sprache xxxxxxx

Setp.: 20.00°C
IntAct xxx.xx°C
ExtAct: xxx.xx°C
Control: intern

Press the respective keys in the following order:

1. MENU

key

1x

2. Enter

key

1x

3. Cursor

key

up to Submenu "Sprache/Language"

4. P-key

1x

5. Enter

key

1x

6. Escape

key

2x


The DIALOG-DISPLAY (LCD) helps to follow up the individual
settings (example: swap the language from German to English).
