DIGI-P122 / DIGI-P123 Installation Guide
RS232 and TCP/IP Commands
RS232 Settings: 9600 baud, 8 Data bits, 1 Stop bit, Parity = None
TCP/IP Settings: User defined IP address, port 4001
=
Carriage return (Hex 0D)
=
Line Feed (Hex 0A)
Switching Commands
Description Command Response
HDMI 1 input select
0701% Source: HDMI 1
HDMI 2 input select
0702% Source: HDMI 2
HDMI 3 input select
0703% Source: HDMI 3
HDMI 4 input select
0704% Source: HDMI 4
VGA 1 input select
0705% Source: VGA 1
VGA 2 input select
0706% Source: VGA 2
VGA 3 input select
0707% Source: VGA 3
VGA 4 input select
0708% Source: VGA 4
Composite video (AV1) input select
0709%
Source: CVIDEO
1
YPbPr input select
0710% Source: YPbPr
S-Video input select
0711% Source: SVIDEO
Composite video (AV2) input select
0712%
Source: CVIDEO
2
Get the currently selected input source
0631%
Displays one of the above
Source: responses
Video Commands
Description Command Response
Set the resolution to 1360x768 (HD)
0618%
Resolution: HD
1360X768
Set the resolution to 1024x768 (XGA)
0626%
Resolution: XGA
1024X768
Set the resolution to 1280x720 (720p)
0627%
Resolution: 720P
1280X720
Set the resolution to 1280x800 (WXGA)
0628%
Resolution: WXGA
1280X800
Set the resolution to 1920x1080 (1080p)
0629%
Resolution: 1080P
1920X1080
Get the currently selected output resolution
0632%
Displays one of the above
Resolution: responses
Aspect Mode – Output Native On
0661% Native On
Aspect Mode – Output Native Off
0660% Native Off
16
