FLX-44 Installation Guide
29
HDCP Commands
/%I/04:0. Turn HDCP Compliance off for input 4
Description Command Response
Turn HDCP Compliance off for input xx /%I/xx:0. /%I/xx:0.
Turn HDCP Compliance on for input xx /%I/xx:1. /%I/xx:1.
Example:
Remote RS232 Control via Routing
The FLX-44 has the logic to pass RS232 commands to remote devices through the TCP/IP or DE9 RS232 ports. The
destination command string is embedded in a command which includes the destination HDBaseT output port and
baud rate. This is a bidirectional communication method. The maximum string length is 48 bytes (characters). In
addition to immediate transmission, the FLX-44 can store commands to be broadcast when the matrix is powered
on or off through the standby commands (PWON. and PWOFF.).
The format of the RS232 routing string is: /+/:<$>. (The period at the end of the string is required.)
is the output code, is the baud rate, and <$> is the RS232 string. Output codes and baud rate codes are
in the tables below.
Baud Baud Code
2400 1
4800 2
9600 3
19200 4
38400 5
57600 6
115200 7
Output Code Timing
1
1 Immediate TX
A PWON command
E PWOFF command
2
2 Immediate TX
B PWON command
F PWOFF command
3
3 Immediate TX
C PWON command
G PWOFF command
4
4 Immediate TX
D PWON command
H PWOFF command
ALL 5 Immediate TX
/C+/4:PowerOn. Send the string PowerOn to output 3 at 19200 baud when the matrix is powered
on.
/C+/4:. Clear power on setting for output 3.
Examples:
