FLX-44 Installation Guide
27
Routing Commands
RS232 and TCP/IP Commands
RS232 Settings: 9600 baud, 8 Data bits, 1 Stop bit, Parity = None
TCP/IP Settings: User defined IP address (default IP address: 192.168.0.178), port 8080
There is either a period (.) or a semicolon (;) at the end of each command. These characters must be present for
the command to process correctly.
There are no spaces between any of the characters in the command string.
xx = Input Number (input 2 would be 02)
yy = Output Number (output 3 would be 03)
= Carriage return (Hex 0D)
= Line Feed (Hex 0A)
Description Command Response
Route input xx to output yy xxByy. AV: xx->0yy
Route input xx to all outputs xxAll. xx To All
Route inputs to corresponding outputs All#. All Through.
Route input xx to multiple outputs yy
Number of outputs is unlimited; each
output must be separated by a comma (,)
xxByy,yy. xxVyy,yy
Turn off all outputs All$. All Closed.
Turn off specific output yy yy$. AV: yy Closed.
Output yy routing status Statusyy. V: xx->0yy
Routing status of all inputs. Status. V: xx->0yy
(Repeating sequence starting with
output 1, output 2, etc�)
02All. Route Video and Audio from input 2 to all outputs
04$. Turn off Video and Audio for output 4
02B03. Route Video and Audio from input 2 to output 3
03B02,04. Route Video and Audio from input 3 to outputs 2 and 4
Examples:
