3.1 Gas inlet temperatures
Components Wetted parts
Housing cover inner part PTFE carbon reinforced
Head cover ETFE
Diaphragm clamping disc ETFE carbon fibre reinforced
Diaphragm PTFE
Valves FFKM
Inlet / outlet ETFE
Hose fittings ETFE
Hose PTFE
Exhaust waste vapor condenser / catchpot Borsilicate glass
3.2 Wetted parts
3.3 Pump parts
Position Component
1 mains connection
2 on/off switch
3 rating plate
4 inlet
5 outlet
6 gas ballast valve
Position Component
7 control cable
8 exhaust waste vapor condenser
9 catchpot
10 coolant inlet
11 coolant outlet
12 overpressure safety relief device
13 accessory foot
Operating condition Inlet pressure
Permitted range of gas
temperatures at inlet
Continuous operation > 100 mbar (high gas load) +10°C to +40°C
Continuous operation < 100 mbar (low gas load) 0°C to +60°C
Short-time (< 5 minutes) < 100 mbar (low gas load) -10°C to +80°C
