2 Interfaces for the Giga Next Series
2.1 1000Mbps TP interface
The
GeoDesy FSO Giga Next series products are designed to provide easy-to-
use and cost-effective solution for interconnecting Local Area Networks. By utilizing
standard Category 5e cable and using standard IEEE802.3af interface the
deployment of the system is easier than ever before. The transparent and wire speed
data transfer together with virtually zero latency assures the easy integration of the
system in all environments.
The
Giga Next systems should be considered as repeaters in the network. So the
installation distance between the head and the network device is 100m. The distance
on a back to back site is maximum 5 meters, between the heads without signal
regeneration.
The
Giga Next systems connecting to the network with two RJ 45 cable which
provides the power required for operation and the data.The power consumption suits
to the standards described in the standard. Also provides fast and easy connection
for the management system for more details please see the chapters below. The
system is certified
Class 1M product , this way 100% eye safe.
2.2 1000 Mbps FO interface
The GeoDesy FSO
Giga Next system is ready to be upgraded with a Single or
Multi mode SC fiber interface with SX or LX option.
The power is provided via the same cable as in the case of the TP interface systems.
