10 Management
10.1 Features
The Inband network-monitoring unit is a newly developed highly featured monitoring
for GeoDesy FSO manufactured laser links. This high quality equipment allows the
user to monitor the link statuses such as detector voltage transmitter status, and
many other features of the Laser link. Nevertheless, this chapter is intended to
describe the usage of this network monitoring, and its connection and relationship
with the GeoDesy FSO laserheads.
The Monitoring system is a standard feature i n the PX-P1000E1000 system. For PX-
P000E1000 it is an optional and has to be activated. After the activation was
purchased, with the invoice number, and the device serial number contact GeoDesy
FSO technical support, for activation code. For further information check Activation
chapter.
Inband monitoring is providing information about
10.1.1 Login Screen and password
The GeoDesy FSO unit arrives with preset values. Such
as user name and password. We strongly recommend
you to change the password after the unit was installed.
The default username is admin, and the password is
admin. If you forget your password contact technical
support to receive your fail-safe password.
10.1.2 Head information screen
The head information screen is the main navigation panel through this screen you will
be able to navigate into the submenu, of the monitoring system.
Device Name: displays the name of the device. Individually can be changed
System Uptime: Diplays the lapsed time from the last boot of the device
IP address: Displays the IP(Internet Protocol) address of the device which must be a
unique identifier in the
network.
Managed head: displays the managed head type.
Head Serial Number: This is the head serial number and during the Activation
process we will ask for this number.
