there you can measure it. In that case if there are not any surfaces for beam
measuring, you can do it in the following method:
Face the remote side and check the beam with your camera. Move slowly to the right
in straight line until the picture of the beam, what you see in the camera, is reducing,
and sign that place. Do the same on the left side. Then you can measure the
distance between the twosigned places. That will be the diameter of the beam. If you
can not use the camera efficiently enough, you can do it with your own eyes too. The
method is the same with one difference, the border of the beam is where. You cannot
see the red dot on the transmitter lens of remote side.

Repeat the setting on both sides with all of the transmitters!

End of the alignment



Switch on all of the transmitters!(in MGM)



Reboot the laser head.



Close up the covers of the heads!
