D Lashing Wire Clamp
Perfect for temporary and permanent terminations or grounds, this all
steel clamp lets you securely attach two lashing wires or #6 ground wire
on any size strand from 1/4 in. to 7/16 in. (6-11 mm) diameter.
P/N 07886 Weight: 15 lbs./100 per carton
Lashing Wire Grip
A screw type grip used to temporarily fasten lashing wire under tension
before placing a permanent clamp like our D or E Lashing Wire Clamps.
P/N 08605 Weight: 10 oz. (.28 kg)
Cable Block Pusher
Pushers lock onto the strand and push the cable blocks out of the way
of the lasher during the cable lashing process. These are especially
useful when lashing multiple cables to allow space between the first
cable block and the lasher.
P/N 70431 Weight: 1.8 lb. (.85 kg)
APPENDIX 3
Accessories
Clip-On Cable Block
This tempered spring steel block is used to support cable up to 1" (2.54
cm) during cable pull-out.
P/N 87265 Weight: 11 lbs. (5 kgs) / package
10701 Cable Block with Rubber Roller
This economical block has a rubber roller & is used for new strand & over-
lash work. Can accommodate up to a 2" (5 cm) cable
P/N 10701 Weight 2 lbs. (.907 kgs)
P/N 73305 Weight 4 oz. (.113 kgs)
73305 Cable Block
This block is used to support one cable up to 1" (25.40 mm) on new
1/4" (6.35 mm) strand. The high strength aluminum frame has a spring-
loaded steel pin that keeps it locked on the strand & the cable on the
nylon roller.
