V - 34
WSW21 (TAD setting 1)
Selector
No.
Function Setting and Specifications
1
|
7
Not used.
8
Erasure of message stored in the
memory after the message
transfer
0: Yes 1: No
l l Selector 8: Erasure of message
Setting this selector to "0" will erase the message recorded in the memory after the document
retrieval feature transfers the message.
WSW22 (ECM setting)
Selector
No.
Function Setting and Specifications
1 ECM* in sending 0: ON 1: OFF
2 ECM* in receiving 0: ON 1: OFF
3
4
Not used.
5
|
8
Acceptable TCF bit error rate (%)
(Only at 4800 bps)
0: 0% 1: 8%
0: 0% 1: 4%
0: 0% 1: 2%
0: 0% 1: 1%
* ECM: Error correction mode
NOTE: Selectors 5 through 8 are applicable to the Asian versions only.
l l Selectors 5 through 8: Acceptable TCF bit error rate (%)
Setting two or more selectors to "1" produces addition of percent assigned to each selector. If you
set selectors 7 and 8 to "1," the acceptable TCF bit error rate will be 3%.
