© Copyright 2006. All rights reserved.

7

IL0170

Cased/Dug Well Installation

Suction Pipe

Priming Plug

Priming Tee

Well Seal

Standing

Water Level

(Pump Off)

Drawdown

Water

Level

(Pump

On)

10 - 20’

At

Least

5 Feet

Figure 11

IL0171

Driven Point Installation

Check Valve

Steel Drive Pipe

Drive Coupling

Well Point

Driven Point

Figure 12

IL0172

Lake Installation

Priming Plug

Priming Tee

Foot Valve

Always

Submerged

Suction

Pipe

Support

Pipe

Screening

protects foot

valve

Foot valve off

bottom to keep

dirt out of system

Figure 13

IL0173

Remove Mechanical Seal

Figure 8

IL0168

Press in Seal

Figure 9

IL0169

If necessary, press
with cardboard and
pipe

3/4” pipe
- press
carefully

Seal

Seal Cavity

Cardboard
washer
protects seal
face

Figure 10

Well Pipe Installation
Use the installation method below which matches
your well type.
