10
This product is warranted for one year from the date of purchase or two years
from the date of manufacture, whichever occurs first. Subject to the conditions
hereinafter set forth, the manufacturer will repair or replace to the original
consumer, any portion of the product which proves defective due to defective
materials or workmanship. To obtain warranty service, contact the dealer from
whom the product was purchased. The manufacturer retains the sole right and
option to determine whether to repair or replace defective equipment, parts or
components. Damage due to conditions beyond the control of the manufacturer
is not covered by this warranty.
THIS WARRANTY WILL NOT APPLY: (a) To defects or malfunctions resulting
from failure to properly install, operate or maintain the unit in accordance with
printed instructions provided; (b) to failures resulting from abuse, accident or
negligence; (c) to normal maintenance services and the parts used in connection
with such service; (d) to units which are not installed in accordance with normal
applicable local codes, ordinances and good trade practices; and (e) the unit is
used for purposes other than for what it was designed and manufactured.
RETURN OF WARRANTED COMPONENTS: Any item to be repaired or
replaced under this warranty must be returned to the manufacturer at Kendallville,
Indiana or such other place as the manufacturer may designate, freight prepaid.
THE WARRANTY PROVIDED HEREIN IS IN LIEU OF ALL OTHER EXPRESS
WARRANTIES, AND MAY NOT BE EXTENDED OR MODIFIED BY ANYONE.
ANY IMPLIED WARRANTIES SHALL BE LIMITED TO THE PERIOD OF
THE LIMITED WARRANTY AND THEREAFTER ALL SUCH IMPLIED
WARRANTIES ARE DISCLAIMED AND EXCLUDED. THE MANUFACTURER
SHALL NOT, UNDER ANY CIRCUMSTANCES, BE LIABLE FOR INCIDENTAL,
CONSEQUENTIAL OR SPECIAL DAMAGES, SUCH AS, BUT NOT LIMITED
TO DAMAGE TO, OR LOSS OF, OTHER PROPERTY OR EQUIPMENT,
LOSS OF PROFITS, INCONVENIENCE , OR OTHER INCIDENTAL OR
CONSEQUENTIAL DAMAGES OF ANY TYPE OR NATURE. THE LIABILITY
OF THE MANUFACTURER SHALL NOT EXCEED THE PRICE OF THE
PRODUCT UPON WHICH SUCH LIABILITY IS BASED.
This warranty gives you specific legal rights, and you may have other rights
which vary from state to state. Some states do not allow limitations on duration
of implied warranties or exclusion of incidental or consequential damages, so the
above limitations may not apply to you.
FOR YOUR WARRANTY PROTECTION, THE WARRANTY REGISTRATION
MUST BE COMPLETED AND RETURNED TO THE WARRANTY
INFORMATION CENTER WITHIN TEN DAYS OF INSTALLATION. WARRANTY
VALID IN CANADA AND MEXICO.
WATER SYSTEMS ONE-YEAR LIMITED WARRANTY
Specifications Chart A
HP
Motor
Pressure
Switch
Setting
Suction
Discharge
Dimensions
Volts Phase HZ RPM
Motor
Connected
For
Inlet Outlet H W L
Ship
Wt.
Lbs.
1/2 115/230V 1 60 3450 115V 30/50 PSI 1-1/4” 1” 8” 10” 17” 36
Pump Performance Chart B
HP
Suction Lift
(Feet)
Gallons Per Minute Capacity At Discharge Pressure PSI
Shut Off PSI
20 30 40 50
1/2
5
15
25
10.1
7.3
4.5
9.6
7.0
4.2 7.8
4.5
3.8 5.5
3.2
2.7 80
79
79
Wiring And Fuse Size Chart C
Motor
HP
Volts
Max.
Load
Amps
Distance In Feet From Motor To Service Panel
Wire Size AWG - Copper
Branch Fuse
Rating†
Wire Size
0-50
Ft.
50-100
Ft.
100-150
Ft.
150-200
Ft.
200-300
Ft.
14 12 10
1/2 115/230V 9.5/4.7 14/14 12/14 12/14 12/14 10/12 15A 20A 30A
(†) Fusetrons are recommended instead of fuses on all motor circuits.
