Festo DAPS..R..-F.. User Manual
Page 5
Switching time [s] per
cycle
1)
DAPS..RS-…
(single-acting)
DAPS..R-...
(double-acting)
DAPS-0008-...
–
0.08
DAPS-0015-…
DAPS-0015-...-CR
0.2
0.24
0.08
0.08
DAPS-0030-…
DAPS-0030-...-CR
0.5
0.50
0.13
0.13
DAPS-0053-...
0.9
–
DAPS-0060-…
DAPS-0060-...-CR
–
1.02
0.2
0.21
DAPS-0090-...
1.3
–
DAPS-0106-...
–
0.4
DAPS-0120-…
DAPS-0120-...-CR
1.7
1.71
–
0.47
DAPS-0180-...
2.7
0.6
DAPS-0240-…
DAPS-0240-...-CR
3.7
3.2
0.8
0.81
DAPS-0360-...
3.9
1.2
DAPS-0480-…
DAPS-0480-...-CR
3.1
1.6
1.54
DAPS-0720-...
5.8
2.7
DAPS-0960-...
6.3
3.1
DAPS-1440-...
19.0
5.5
DAPS-1920-...
15.0
6.0
DAPS-2880-...
19.0
16.0
DAPS-3840-...
–
12.0
DAPS-4000-...
25.0
–
DAPS-5760-...
–
16.0
DAPS-8000-...
–
22.0
1)
Average values under idle conditions
Product weight [kg]
DAPS..RS-…
1)
(single-acting)
DAPS..R-…
(double-acting)
DAPS-0008-...
–
0.3
DAPS-0015-...
DAPS-0015-...-CR
1 … 1.2
1.7
0.75
0.9
DAPS-0030-...
DAPS-0030-...-CR
1.65 … 1.95
2.4
1
1.3
DAPS-0053-…
2.6 … 3
–
DAPS-0060-...
DAPS-0060-...-CR
–
4.5
1.6
1.8
DAPS-0090-...
5 … 5.9
–
DAPS-0106-...
–
2.5
DAPS-0120-...
DAPS-0120-...-CR
5.8 … 6.8
7.6
–
3.3
DAPS-0180-...
7.4 … 8.9
4.6
DAPS-0240-...
DAPS-0240-...-CR
10.2 … 11.8
12.9
5.4
5.6
DAPS-0360-...
14.5 … 16.5
6.5
DAPS-0480-...
DAPS-0480-...-CR
19.3 … 22.7
–
9.6
9.5
DAPS-0720-...
26.2 … 33
12
DAPS-0960-...
36 … 42
17.4
DAPS-1440-...
74
23.4
DAPS-1920-...
67
32
DAPS-2880-...
117
56
DAPS-3840-...
–
49
DAPS-4000-...
183
–
DAPS-5760-...
–
86
DAPS-8000-...
–
106
1) Product weight is dependent on the spring strength (
www.festo.com/catalogue).
Information on materi-
als
DAPS-...
DAPS–...–T6
DAPS–...–CR
Seals
Nitrile rubber
Polyurethane (PUR)
Fluoro elastomer
FVMQ
PTFE-reinforced
Nitrile rubber
Polyurethane (PUR)
Fluoro elastomer
Shaft
High-alloy steel (1.4305)
High-alloy stainless
steel (1.4301)
Cover
Wrought aluminium alloy
High-alloy stainless
steel (1.4408)
Housing
Screws
High-alloy steel
High-alloy stainless
steel
