Manual EKS Electronic-Key Adapter serial
088796-02-03/05 Subject to technical modifications Page 22/24
8.6 Command overview
Description Command message Reply message
Program (write) Electronic-Key TP (see chapter 8.4.1) RF (see chapter 8.4.1)
Read Electronic-Key
(also read the serial number) TL (see chapter 8.4.2 and 8.4.3) RL (see chapter 8.4.2)
or
RF (see chapter 8.4.2)
Reset device TA (see chapter 8.5) RF (see chapter 8.5)
8.7 Status numbers
Value Description
00
hex
No error
02
hex
Electronic-Key not in the operating distance
03
hex
Parity bit error on Electronic-Key read-only
06
hex
Write process aborted. Start address or number of bytes is not a multiple of the block size 4
17
hex
Read attempt when the Electronic-Key adapter is set to Electronic-Key read/write and an Electronic-Key
read-only is inserted
18
hex
Read attempt when the Electronic-Key adapter is set to Electronic-Key read-only and an Electronic-Key
read/write is inserted
4x
hex
General Electronic-Key communication error (renewed write or read necessary)
50
hex
Write attempt despite enabled write protection
