Manual EKS Electronic-Key Adapter serial

088796-02-03/05

Subject to technical modifications

Page 20/24

Contents

Byte no.

Description

ASCII

hexadecimal

decimal

0

Number of message bytes

08 ... 7B

8 ... 123

1
2

Command identification

R

L

52

4C

82
76

3

Device address

01

1

4
5

Start address for the user data

00

00 ... 73

0

0 ... 115

6

Number of bytes of user data

01 ... 74

1 ... 116

7 ... 122

User data

ASCII or hexadecimal or BCD (code transparent)

Figure 5: Reply message read Electronic-Key read/write (message core)

Contents

Byte no.

Description

ASCII

hexadecimal

decimal

0

Number of message bytes

07

7

1
2

Command identification

R

F

52
46

82
70

3

Device address

01

1

4
5

Padding data

00
00

0
0

6

Status number

*

Figure 6: Reply message read Electronic-Key read/write - status (message core)

* Status number

02

hex

:

Electronic-Key not in the operating distance

(For further status numbers see chapter 8.7)

8.4.3 Reading the serial number

The Electronic-Key read/write contains a unique 8-byte serial number. This number is written by laser during the
Electronic-Key production process and can never be changed or deleted. The serial number is used for reliable
identification of each individual Electronic-Key. It is necessary that all 8 bytes are completely evaluated for
reliable differentiation. The serial number is appended to the freely programmable user data.

The serial number can be read using the command TL (see section 8.4.2 Read process) using the start address
byte no. 116 and 8 as the number of bytes.
