Operating Instructions Safety Switch CET.-AP-...-AH-...
33
Ordering information and accessories
Versions for connection to decentralized peripheral
systems (2 x M12, 5-pin, pin 5 not used)
Connection cables for connection to decentralized
peripheral systems
Accessories
Designation Comment Order no./item
Connection cable M12
PVC, 5-core, plug connectors at both ends
(for connection to decentralized peripheral systems)
M12 female plug 5-pin to M12 male plug, length 5 m 100180
M12 female plug 5-pin to M12 male plug, length 10 m 100181
M12 female plug 5-pin to M12 male plug, length 20 m 100182
Designation Use Version Order No./item
Mechanical key release for safety switch CET identical locking, incl. 2 keys
098850
Mechanical key release
Replacement key
for mechanical key release, identical
locking
2 keys, identical locking
099434
Replacement key
Emergency unlocking for safety switch CET latching in both positions
103714
Emergency unlocking CET
Cover
for safety switch CET
and actuators CET
door hinge right
098808
CET cover right
door hinge left
098807
CET cover left
Handle for wire front release
(Bowden)
for safety switch CET
099795
Handle for wire front release (Bowden)
Mounting plate EMP-L-CET for safety switch CET
106695
EMP-L-CET
Mounting plate EMP-B-CET for actuator CET
106694
EMP-B-CET
Actuator for safety switch CET incl. safety screws
096327
CET-A-BWK-50X
Safety screws (spare) for actuator CET
4 x M5 x 16
packaging unit: 100 ea.
073456
M5 x 16
Order No./item
Closed-cir
cuit
curr
ent
principle Open-cir
cuit
curr
ent
principle Door
monitoring
output
Unicode Multicode Single
inser
tion
slide
Double
inser
tion
slide
Teach-in
input
Feedback
loop
Escape
r
elease
W
ir
e
fr
ont
r
elease
Lockout
mechanism
W
iring
diagram
CET3
111346
CET3-AP-CRA-AH-50X-SI-111346
l l l B
114223
CET3-AP-CRA-AH-50X-SI-C2333-114223
l l l l B
114626
CET3-AP-CRA-AH-50F-SI-C2357-114626
l l l
l
105 mm
l B
114073
CET3-AP-CRA-AH-50F-SI-114073
l l l
l
75 mm
B
114516
CET3-AP-CRA-AH-50F-SI-C2333-114516
l l l
l
75 mm
l B
CET4
112082
CET4-AP-CRA-AH-50X-SI-112082
l l l B
* For connection of the device, observe the specifications in the corresponding application example at www.euchner.de, in the area Download » Applications » CET.
